NEW - PULLMASTER PL SERIES

PULLMASTER PL1-12-227-1 HYDRAULIC WINCH


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

KEY: PL1:12:227:1

Manufacturer: PULLMASTER

Model: PL1-12-221-1

Sale Price: Request Quote

Instructions: <Click Here>

Quantity:

Additional Information

EQUAL SPEED IN BOTH DIRECTIONS
Hydraulic gear motor.
Spring-applied, pressure-released, automatic multi-disc brake.
Over-running clutch enables free rotation in the hoisting direction.
During lowering operations, the over-running clutch locks causing the disc brakes to rotate between a series of divider discs. Dynamic braking is then achieved by a hydraulic pilot signal from the pay-out port. When the control is returned to neutral position, the brake applies automatically.
Thus, a counter-balance valve is not required for smooth and precise pay-out load control.
BARE DRUM: Line Pull: 1,100 lbs / 78 fpm
FULL DRUM: Line Pull: 821 lbs / 104 fpm
DRUM CAPACITY: 87 ft of 1/4"
