BARGE - P2 7'

P2-7' 90'X100' 300T CRAWLER CRANE BARGE


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

KEY: P27300TONCRAWLER

Daily: Request Quote

Instructions: <Click Here>

Quantity:

Additional Information

CRANE: 300ton Crawler
Barge Type: P2-7
Working Weight: 650,000 lbs.
Boom Length: 200 ft.
Picking Weight: 140,000 lbs.
Pick Radius: 75 ft.
Pick Height: 185 ft.
Crane Mats: 51,200 lbs.
Misc Weight: 350,000 lbs.
Total Deck Payload: 1,191,200 lbs.
Accessory Weight: 20,960 lbs.
PLATFORM:
Qty (18) 40X10X7 Barges: 604,800 lbs.
Qty (9) 20X10X7 Barges: 164,880 lbs.
Qty (4) P10 Spud Pockets: 16,000 lbs.
Total Hull Weight: 785,680 lbs.
ACCESSORIES:
Qty (380') Handrail: 4560 lbs.
Qty (2) HPU PMW: 9,600 lbs.
Qty (4) Umbilical: 400 lbs.
Qty (4) PMW: 6,400 lbs.
Accessory Weight: 20,960 lbs.
HYDROSTATICS:
Average Platform Draft: 3.56 ft. freshwater
Waterplane Area: 9,000 sq ft.
Vertical Center of Buoyancy: 1.78 ft.
Stability Metrics:
Working over end of platform: Trim Moment: -10,568,800 ft-lbs.
Working over side of platform: List Moment: 10,509,600 ft-lbs.
List Angle (deg) Port to Starboard: 1.8
Trim Angle (deg) Bow to Stern: -1.4

* Please call us with any questions about our p2 7 foot 90 foot x100 foot 300t crawler crane barge in Belle Chasse LA, Seattle WA, Chesapeake VA, Williamstown NJ, and the East, West, and Gulf Coasts areas.
