BARGE - P2 7'

P2-7' 80'X90' 230T CRAWLER CRANE BARGE


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

KEY: P27230TONCRAWLER

Daily: Request Quote

Quantity:

Additional Information

CRANE: 230 ton Crawler
Barge Type: P2-7
Working Weight: 460,000 lbs.
Boom Length: 200 ft.
Picking Weight: 95,000 lbs.
Pick Radius: 65 ft.
Pick Height: 189 ft.
Crane Mats: 44,800 lbs.
Misc Weight: 250,000 lbs.
Total Deck Payload: 849,800 lbs.
Accessory Weight: 20,480 lbs.
PLATFORM:
Qty (13) 40X10X7 Barges: 604,800 lbs.
Qty (6) 20X10X7 Barges: 109,920 lbs.
Qty (4) P2-7 Spud Pockets: 16,000 lbs.
Total Hull Weight: 1,433,000 lbs.
ACCESSORIES:
Qty (340') Handrail: 4,080 lbs.
Qty (2) HPU PMW: 9,600 lbs.
Qty (4) Umbilical: 400 lbs.
Qty (4) PMW: 6,400 lbs.
Accessory Weight: 20,480 lbs.
HYDROSTATICS:
Average Platform Draft: 3.59 ft. freshwater
Waterplane Area: 6,400sq ft.
Vertical Center of Buoyancy: 1.79 ft.
Stability Metrics:
Working over end of platform: Trim Moment: -6,258,200 ft-lbs.
Working over side of platform: List Moment: 6,179,800 ft-lbs.
List Angle (deg) Port to Starboard: 1.9
Trim Angle (deg) Bow to Stern: -2.0

* Please call us with any questions about our p2 7 foot 80 foot x90 foot 230t crawler crane barge in Belle Chasse LA, Seattle WA, Chesapeake VA, Williamstown NJ, and the East, West, and Gulf Coasts areas.
