BARGE - P2 5'

P2-5' 70'X80' 150T CRAWLER CRANE BARGE


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

KEY: P25150TONCRAWLER

Daily: Request Quote

Quantity:

Additional Information

CRANE: 150ton Crawler
Barge Type: P2-5
Working Weight: 285,000 lbs.
Boom Length: 150 ft.
Picking Weight: 50,000 lbs.
Pick Radius: 50 ft.
Pick Height: 141 ft.
Crane Mats: 40,320 lbs.
Misc Weight: 36,000 lbs.
Total Deck Payload: 411,320 lbs.
Accessory Weight: 20,240 lbs.
PLATFORM:
Qty (12) 40X10X5 Barges: 313,800 lbs.
Qty (4) P2-5' - Spud Pockets: 12,400 lbs.
Total Hull Weight: 326,200 lbs.
HYDROSTATICS:
Average Platform Draft: 2.53 ft. freshwater
Waterplane Area: 4,800 sq ft.
Vertical Center of Buoyancy: 1.26 ft.
Stability Metrics:
Working over end of platform: Trim Moment: -2,693,367 ft-lbs.
Working over side of platform: List Moment: 2,500,000 ft-lbs.
List Angle (deg) Port to Starboard: 1.2
Trim Angle (deg) Bow to Stern: -1.5
ACCESSORIES:
Qty (2) HPU PMW: 9,600 lbs.
Qty (4) PMW: 6,400 lbs.
Qty (4) Umbilical hose: 400 lbs.
Qty (240): Handrail (ft.): 3,360 lbs.
Qty (8) Deck Cleat: 480 lbs.

* Please call us with any questions about our p2 5 foot 70 foot x80 foot 150t crawler crane barge in Belle Chasse LA, Seattle WA, Chesapeake VA, Williamstown NJ, and the East, West, and Gulf Coasts areas.
