NEW - FAIRLEAD 4 ROLLER

FAIRLEAD 4 ROLLER SMITH BERGER 100MT


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

KEY: FR4:10

Manufacturer: SMITH BERGER MAR

Model: FR4-10

Instructions: <Click Here>

Quantity:

Additional Information

STANDARD FEATURES
Designed with a S.W.L. of 100MT (220,460 Lbs or 980.7 kN)
per O.C.I.M.F. Rev.3 Guidelines.
Hardened Rollers for Longer Life
Grease Lubricated Bronze Bearings
Epoxy Primer Coating
Sheave Diameter: Vertical & Horizontal Roller=10" Dia.
Approx. Dimensions: L=36" x W=23-3/4" x H=35-13/16"
Weight: 3,350 lbs.
OPTIONAL FEATURES
Customized Design to Suit Your Application
Seawater Lubricated Bearings for Underwater Use
Bolt Down Mounting Base
Stainless Steel Rollers
Load Monitoring System
Three Coat Marine Paint System
Third Party Certification

* Please call us with any questions about our fairlead 4 roller smith berger 100mt in Belle Chasse LA, Seattle WA, Chesapeake VA, Anderson CA, Williamstown NJ, and the East, West, and Gulf Coasts areas.
